R-LINE
Rotary Filling & Sealing Machine
Innovative Design Concept, Highest Modularity and Flexibility
The R-Line is a rotary filler for a wide range of applications that introduces an innovative design concept that accomplishes remarkable improvements in terms of flexibility, accessibility, and sustainability.
Liquid to pasty products can be filled in different sizes of pre-formed cups, tubs, buckets, glass jars, and bottles. The machine can run with either mono-material or paper based cups and lids, both recyclable and in accordance with sustainability practices.
Depending on the cup size and volume, the R-Line offers an output range up to 36.000 cups/h.
settings_applications
Production Plant
IMA Dairy & Food Gasti
R-LINE Highlights
1.
Complete open and hygienic body without table plate.
2.
Wash down design.
3.
Comfortable operating height.
4.
Hygienic equipment from „Clean“ up to „Aseptic Ready“.
5.
Maximum flexibility through future-proofed design.
6.
Wide output range with single and double step concept.
Products to be filled
Handling all products from liquid to high viscous - with or without particulates - such as yoghurt, fresh cheese, quark, desserts, milk, cream, butter, aerated mousse products, deli salads, dips, dressings, hot fill sauce, soups, jam and fruit purees, tomato paste, margarine, humus, beverages (water, coffee, tea, juices, alcohol based drinks) as well as other liquid to pasty products like pet food, creams.
Cup formats
Different kind of cup formats of pre-formed cups and tubs can be filled.
- Technical Data
| Machine Versions and Dimensions | ||||
| S-Type | M-Type | L-Type | XL-Type | |
| Rotary disc Ø | 1.000 mm | 1.540 mm | 2.080 mm | 2.620 mm |
| Footprint | 1.700 x 1.700 mm | 2.400 x 2.400 mm | 2.900 x 2.900 mm | 3.400 x 3.400 mm |
| Container formats | Filling volume: up to 2.500 ml | Round Ø: 175 mm | Square: 175 mm | Height: 180 mm |
| Container | PP, PS, PET, paper, Plastic cup with cardboard sleeve (e. g. K3®, Desto), glass |
|||
| Lid | PP, PET, Alu compound, Alu with coex layer (e. g. ComforLid) | |||
| Snap-on lids |
PET, PP or PS | |||
| Standards | ||||
| Standard configuration | Vertical cup destacker, filling station (CIP-capable), incl. nozzles & capacitive level control, sealing lid applier, heat sealing, cup lifting out | |||
| Hygiene class | Clean (VDMA I+II) | |||
| Options | ||||
| Hygiene class | Ultra-clean (VDMA III+IV) | |||
| Filler | Pre- and post-filler | |||
| General | Cup stack buffer magazine, particle remover, leakage test, inkjet printing, snap-on lid, format flexibility | |||
| Decontamination |
UVC, Pulsed Light |
|||
