Medium speed case packer designed to handle the widest range of products and materials used in pharmaceutical, with maximum ease of use and total control of the packaging process
Medium speed case packer designed to handle the widest range of products and materials used in pharmaceutical, with maximum ease of use and total control of the packaging process
Fully automatic side loading case packer designed to satisfy all of your current and future case packing requirements.
The machine has been built to maximize efficiency and ease of use in an ever increasingly demanding work place, to guarantee complete line clearance and to ensure total access to all modules.
The CPH2 is designed to ensure total control throughout all stages of the serialization process.
Flexibility, maximum efficiency, total access and total control make the CPH2 a casepacker of new generation.
CPH2 is available in different palletizer-integrated versions, according to the output required:
CPH2-RP2
With automatic replacement of the full pallet and case buffering during pallet replacement or with two pallet stations; once one pallet is complete, the robot starts loading the second pallet
CPH2-RP4
With 4 pallet stations for greater autonomy. When the pallet is complete, the automatic transport moves the pallet to the exit area and replaces it with an empty one.
CPH2 TECHNICAL DATA | |||
Case dimensions | A | B | C |
Min. | 220 | 100 | 90 |
Max. | 600 | 400 | 400 |
Product dimensions | a | b | c |
Min. | 25 | 22 | 60 |
Max. | 590 | 70/150 | 220 |
Speed | 10 cases/min. |
