GS
Coating pans

GS Coating Equipment features innovative technology with an awareness of the issues related to environment, energy saving and reliability. Available in different models, GS machines allows the processing of all product shapes and sizes.

GS Coating Equipment features innovative technology with an awareness of the issues related to environment, energy saving and reliability. Available in different models, GS machines allows the processing of all product shapes and sizes.

The coating pan that made history.

GS Coating Equipment is the ideal solution for all manufacturing needs: powder layering, film and sugar coating.
Patented exhausting or blowing paddles convey the drying air through the cores bed. This makes for the reduction of process times and thus the air volume needed.

IMA Active
settings_applications Production Plant
IMA Active

GS Highlights

1.
Perfect mixing and uniform distribution of coating material thanks to the shape of the pan and surface smoothness.
2.
Patented drying system.
3.
Different paddle sizes for higher flexibility in terms of pan working capacities.
4.
Automatic product load and discharge.
The smooth surface of the solide wall pan enables simple and fast cleaning operations. Different cleaning programmes, comprising washing, rinsing and discharge, can be developed according to different products and stored in the recipes.

Lab Version.

Using the same highly advanced technologies as those developed for the production range, GS laboratory equipment allows maximum flexibility and easy scale-up. A high degree of automation ensures easy operations and maintenance procedures can be applied.

GS Thumbnail
  • Technical Data
  • Machine Layout
TECHNICAL DATA GS HT – HE – HP
Model GS 70 GS 150 GS 300 GS 400 GS 600
Minimum/maximum working capacity (l)* 40÷70 70÷150 150÷300 200÷400 350÷600
Pan diameter (mm) 1,050 1,280  1,580 1,630  2,000
Pan mouth diameter (mm) 400 450  520   730
Pan motor power (kW) 1.1 1.5  3 4 5.5
Process air delivery (m³/h) 800 1,100 2,000 2,500 3,500
Power consumption for standard equipment (kW)** 10 12 20 25 30
* Approximate data (depending on core shape and specific weight)
** Approximate data (depending on equipment configuration)



TECHNICAL DATA GS LABORATORY EQUIPMENT
Model HT 0.5-3*** HT 3 HT 10 HT-HP 25
Minimum/maximum working capacity (l)* 0.5÷4 2÷4 5÷12 13÷25
Pan diameter (mm) 450 600 800
Pan mouth diameter (mm) 215  300
Pan motor power (kW) 0.22 0.37
Process air delivery (m³/h) 80 150 350
Power consumption for standard equipment (kW)** 6 10 14
* Approximate data (depending on core shape and specific weight)
** Approximate data (depending on equipment configuration)
***Interchangeable drum
GS Layout

GS Gallery

keyboard_arrow_left
keyboard_arrow_right
search
Spray guns
search
Solid wall pan
search
Film coating
search
Small cores processing
search
Powder dosing device
search
Product unloading
